Single Phase Hybrid Inverter
SUN-3K-SG04LP1-24-EU
- Direct supply from the manufacturer
- Order phone：+86-17625817768
- E-mail：sales@pandaess.com
- Datasheet
Technical Data
| Model |
SUN-3K-SG04LP1 -24-EU-SM1 |
SUN-3K-SG04LP1 -EU-SM1 |
SUN-3.6K-SG04LP1 -EU-SM2 |
SUN-5K-SG04LP1 -EU-SM2 |
SUN-6K-SG04LP1 -EU-SM2 |
||
| Battery Input Data | |||||||
| Battery Type | Lead-acid or Lithium-ion | ||||||
| Battery Voltage Range(V) | 20-30 | 40-60 | 40-60 | 40-60 | 40-60 | ||
| Max.Charging Current(A) | 140 | 70 | 90 | 120 | 135 | ||
| Max.Discharging Curent (A) | 140 | 70 | 90 | 120 | 135 | ||
| ExternalTemperature Sensor | Yes | ||||||
| Charging Curve | 3Stages/Equalization | ||||||
| ChargingStrategy for Li-lon Battery | Self-adaption to BMS | ||||||
| PV String Input Data | |||||||
| Max DCInput Power(W) | 3900 | 3900 | 4680 | 6500 | 7800 | ||
| Rated PVInput Voltage(V) | 370(125-500) | ||||||
| Start-upVoltage(V) | 125 | ||||||
| MPPTVoltage Range(V) | 150-425 | ||||||
| Full LoadDCVoltage Range(V) | 300-425 | ||||||
| PVInput Current(A) | 13 | 13+13 | |||||
| Max.PVlsc(A) | 17 | 17+17 | |||||
| No.ofMPPTrackers | 1 | 2 | |||||
| No.of Strings per MPPTracker | 1+1 | ||||||
| ACOutput Data | |||||||
| RatedACOutput Active Power (W) | 3000 | 3600 | 5000 | 6000 | |||
| MaxACOutput Active Power (W) | 3300 | 3960 | 5500 | 6600 | |||
| ACOutput Rated Current(A) | 13.6/13 | 16.4/15.7 | 22.7/21.7 | 27.3/26.1 | |||
| Max.ACOutput Current (A) | 15/14.3 | 18/17.2 | 25/23.9 | 30/28.7 | |||
| Max.ContinuousACPassthrough(A) | 35 | 40 | |||||
| Peak Power(ofgrid) | 2time of rated power,10S | ||||||
| Dowwer Eactor Adiustment Range | 0.8 leading to0.8 lagging | ||||||
| Power Factor | 1 | ||||||
| Output Frequency and Voltage | 50/60Hz;L/N/PE 220/230Vac | ||||||
| Grid Type | Single Phase | ||||||
| TotalHarmonics Current Distortion (THDi) | <3%(of nominal power) | ||||||
| DCCurrent Injection | <0.5%In | ||||||
| Eficiency | |||||||
| Max.Effciency | 97.60% | ||||||
| Euro Efciency | 96.50% | ||||||
| MPPTEffciency | 99.90% | ||||||
| Protection | |||||||
| Integrated |
Anti-islanding Protection,PVString Input Reverse Polarity Insulation Resistor DetectionResidual Current Monitoring Unit,Output Output Shorted Protection,Surge ProtectionProtection, Over CurrentProtection, |
||||||
| Over Voltage Category | DCType lI/ACType lII | ||||||
| Certifcations and Standards | |||||||
| Grid Regulation |
IEC61727,IEC62116,CEI0-21,EN50549,NRS097,RD 140,UNE 217002, OVE-Richtlinie R25,G99,VDE-AR-N4105 |
||||||
| Safety/EMC Standard | IEC/EN61000-6-1/2/3/4,IEC/EN62109-1,IEC/EN62109-2 | ||||||
| General Data | |||||||
| Operating Temperature Range(℃) | -40to+60°℃,>45°℃Derating | ||||||
| Cooling | Free Cooling | Smart Cooling | |||||
| Noise(dB) | ≤30dB | ||||||
| Communication with BMS | RS485;CAN | ||||||
| Weight(kg) | 14 | 15 | |||||
| Cabinet Size(WxHxDmm) | 330×433×238(Excluding Connectors and Brackets) | ||||||
| Protection Degree | IP65 | ||||||
| Installation Style | Wall-mounted | ||||||
| Warranty | 5Years(10Years Optional) | ||||||
Product advantages
