Single Phase Hybrid Inverter
SUN-3/3.6/5/6K-SG04L
- Direct supply from the manufacturer
- Order phone：+86-17625817768
- E-mail：sales@pandaess.com
- Datasheet
Technical Data
| Model |
SUN-3K -SG04LP1-24-EU |
SUN-3K -SG04LP1-EU |
SUN-3.6K -SG04LP1-EU |
SUN-5K -SG04LP1-EU |
SUN-6K -SGO4LP1-EU |
|||||
| Battery Input Data | ||||||||||
| Battery Type Lead-acid or Lithium-ion | ||||||||||
| Battery Voltage Range(V) 20-30 | 40-60 | 40-60 | 40-60 | 40-60 | ||||||
| Max.Charging Current(A) 140 | 70 | 90 | 120 | 135 | ||||||
| Max.Discharging Curent (A) 140 | 70 | 90 | 120 | 135 | ||||||
| ExternalTemperature Sensor Yes | ||||||||||
| Charging | Curve | 3Stages/Equalization | ||||||||
| Charging | Strategy for Li-lon Battery | Self-adaption to BMS | ||||||||
| PV String Input Data | ||||||||||
| Max DCInput Power(W 3900 | 3900 | 4680 | 6500 | 7800 | ||||||
| Rated PVInput Voltage(V) 370(125-500) | ||||||||||
| Start-upVoltage(V) 125 | ||||||||||
| MPPTVoltage Range(V) 150-425 | ||||||||||
| Full LoadDCVoltage Range(V) 300-425 | ||||||||||
| PVInput Current(A) | 13 | 13+13 | ||||||||
| Max.PVlsc(A) | 17 | 17+17 | ||||||||
| No.ofMPP Trackers | 1 | 2 | ||||||||
| No.of Strings per MPP Tracker | 1 | 1+1 | ||||||||
| ACOutput Data | ||||||||||
| RatedACOutput Active Power (W) | 3000 | 3600 | 5000 | 6000 | ||||||
| Max.ACOutputActive Power (W) | 3300 | 3960 | 5500 | 6600 | ||||||
| ACOutput Rated Current(A) | 13.6/13 | 16.4/15.7 | 22.7/21.7 | 27.3/26.1 | ||||||
| Max.ACOutput Current(A) | 15/14.3 | 18/17.2 | 25/23.9 | 30/28.7 | ||||||
| Max.ContinuousACPassthrough(A) | 35 | 40 | ||||||||
| Peak Power(ofgrid) | 2time of rated power,10S | |||||||||
| Dowwer Eactor Adiustment Range | 0.8 leading to0.8 lagging | |||||||||
| Power Factor | 1 | |||||||||
| Output Frequency and Voltage | 50/60Hz;L/N/PE 220/230Vac | |||||||||
| Grid Type | Single Phase | |||||||||
| TotalHarmonics Current Distortion(THDi) | <3%(of nominal power) | |||||||||
| DCCurrent Injection | <0.5%In | |||||||||
| Eficiency | ||||||||||
| Max.Effciency | 97.60% | |||||||||
| Euro Efciency | 96.50% | |||||||||
| MPPTEffciency | 99.90% | |||||||||
| Protection | ||||||||||
| Integrated |
Anti-islanding Protection,PVString Input Reverse Polarity Insulation Resistor DetectionResidual Current Monitoring Unit,Output Output Shorted Protection,Surge ProtectionProtection, Over CurrentProtection, |
|||||||||
| Over Voltage Category | DCType lI/ACType lII | |||||||||
| Certifcations and Standards | ||||||||||
| Grid Regulation |
IEC61727,IEC62116,CEI0-21,EN50549,NRS097,RD 140,UNE 217002, OVE-Richtlinie R25,G99,VDE-AR-N4105 |
|||||||||
| Safety/EMC Standard | IEC/EN61000-6-1/2/3/4,IEC/EN62109-1,IEC/EN62109-2 | |||||||||
| General Data | ||||||||||
| Operating Temperature Range(℃) | -40to+60℃,>45℃Derating | |||||||||
| Cooling | Free Cooling | Smart Cooling | ||||||||
| Noise(dB) | ≤30dB | |||||||||
| Communication with BMS | RS485;CAN | |||||||||
| Weight (kg) | 14 | 15.1 | ||||||||
| Cabinet Size(WxHxDmm) | 330×433×238(Excluding Connectors and Brackets) | |||||||||
| Protection Degree | IP65 | |||||||||
| Installation Style | Wall-mounted | |||||||||
| Warranty | 5Years(10Years Optional) | |||||||||
Product advantages
